    Computing the sun position

    Focasting the positions of the Sun, Moon and planets has a long story. This required long nights of observations recorded by the Babylonians (circa -1000). More recently, during the Hellenistic period of Greece, the ancient greeks were able to create the first analog computer (the Antikythera mechanism circa -100).

    The next mile stone was Newton’s law, fundamental in Mechanics, which is maybe a result of confinement: “Soon after Newton had obtained his BA degree in August 1665, the university temporarily closed as a precaution against the Great Plague. Although he had been undistinguished as a Cambridge student, Newton’s private studies at his home in Woolsthorpe over the subsequent two years saw the development of his theories on calculus, optics, and the law of gravitation.” Proof of Kepler’s equation came later in 1679.

    First computers were of course human computers (e.g. bavarian gunners of Petzal lens 1840; organized according to a program, a “calculation plan”), or Marine officers for computation of “Droite de hauteur” with Sextant. But, the famous one were the “female computers” in the context of WWII and space conquest. On of these women is Katherine Johnson (deceased recently in feb 2020 and popularized by the film “Hidden Figures”). John Glenn refused to fly unless Johnson verified the calculation by hand of his 1962 trajectory (computed by a FORTRAN 54 computer).

    Computation of the positions of planets was the computational challlenge in the early days of hand held computing. From hp RPN (starting from hp 65 1974), to BASIC (Meeus used a BASIC HP-85, he did a computation which took 470 hours and dissipated 120kWH, many books and programs have been written around the 80’ (Sérane prosed programs for popular BASIC computers in the late 80’ etc). I guess that the formulas used by Meeus, Bouiges and others come from Danjon “Astronomie générale”, but I have to check. The final tables of Meeus, have been coded in web pages by many astromers (here or there) googling the numerical values 33.231+%2B+13.17639653*N leeds to some page of code…

    Of course the “Bureau des Longitudes” provides every year its “Ephémérides Nautiques” and “Ephémérides Astronomiques” with rigorous position of all the planets. This is the reference.




    This program (in standard C) computes the position (cartesian and angular) of the Sun at any time (given UTC time, day, month and year) and any where in the word (for given latitude and longitude) using Bouiges 1981 and Meeus 1988,2014 simplified algorithms. An approximation for the Moon is given as well (to be continuated, only a first approximation).

    • The Kepler equation is solved. Some changes (rotations) of frameworks (ecliptic, equatorial…) are done to obtain final azimuth and hight of Sun and Moon.

    • This program can be used to find the true North using the azimuth of the sun for use with a Bagnold sun-compas (Bagnold and King 1931, Gross 2011).

    • This program can be used to find the height of the sun for nautical celestial navigation with a sextant (Sacaze 1980, Caradec 1977).

    • As a result we plot a sundial (position of projection of the top of the gnomon on the soil, with analemma at noon) or “Cadran Solaire” (Camus & Gotteland 1993), we plot it with “brute force” without any simplification (as found in books on sundials, Opizzo 1990…).

    • We compute as well by “brute force” the equation of time (difference between time on a sundial and real time).



    Tools

     #include <stdio.h>
 #include <stdlib.h>
 #include <math.h>
 #include <string.h>
 #include <time.h>

    Caution, all angles in degree (historical use), pay attention to Kepler Equation where there is a mix

    double sindeg(double theta){
    return sin(pi*theta/180);
}
double cosdeg(double theta){
    return cos(pi*theta/180);
}
double tandeg(double theta){
    return tan(pi*theta/180);
}

    conversion from decimal to sexagesimal HMS function of HP calculator.

    char* HMS(double angle,char *symb){
    static char chaine[15];
    double s=1;
    if(angle<0) s=-1;
    angle = s*angle;
    double dd = (int)(angle);
    double mm = (int)(60*(angle - dd));
    double ss = ((angle - dd) - mm/60)*60*60;
    if (ss==60) {ss=0;mm=mm+1;}
    if (mm==60) {dd=dd+1;}
    sprintf (chaine,"%.0f%s%2.fmn%2.1fs", s*dd,symb,mm,ss);
    return chaine;
}

    computation itself

    double hauteur,azimut;
int check;

void calc(double J, double M, double A, double heureTU, double lat, double longit){

    number of days since 00/01/1901 , from “SHOM Table des Marées des grands ports du Monde 1984” see as well Bouiges p 32 and “Date Algorithms” By Peter Baum ) hours in UTC, latitude (positive North) and longitude (positive W) in decimal degrees

        double Nj =
    floor(30.6001*(1 + M + 12*floor(0.7 + 1/(1 + M))))+
    floor(365.25*(A - floor(0.7 + 1/(1 + M))))
    -694403 + heureTU/24. + J ;
    ;

    Kepler Equation for Sun position

    position of Sun, see Bouiges p 37:
    L longitude moyenne hypothétique, note that 360/365.2425=0.985647342, one year for a complete turn
    \bar \omega longitude du périhélie.
    with a given excentricity e=0.01675
    Values of Meeus are nearly the same, but he proposes quadratic corrections

    Cartesian position x and y of the Sun, u anomalie excentrique et v l’anomalie vraie :
     reset
 set size square
 set parametric
 set trange [0:2*pi]

 e=.8
 fx(t) = cos(t)
 fy(t) = sin(t)

 v(t)=arcos(cos(t)-e)/(1-e*cos(u))
 fxe(t) = cos(t)
 fye(t) = sqrt(1-e*e)*sin(t)

 a=1.
 set arrow 1 nohead from 0,0 to cos(a),sin(a)
 set arrow 2 nohead from cos(a),0 to cos(a),sin(a)
 set arrow 3 nohead from e,0 to cos(a),sqrt(1-e*e)*sin(a)
 set arrow 4 nohead from 0,0 to e,0
 set label 1 "u" at .1,.1
 set label 2 "v" at .05+e,.1
 set label 3 "O" at .05,-.1
 set label 4 "F" at .05+e,-.1
 set xrange[-1.5:1.5]
 set yrange[-1.5:1.5]
 plot fx(t),fy(t) not ,fxe(t),fye(t) t'Earth trajectory'

 unset arrow 1
 unset arrow 2
 unset arrow 3
 unset label 1
 unset label 3
 unset label 4

 reset
    (script)

    (script)

        double L = 278.965 + 0.985647342*Nj;
    double omb = 281.235 + 0.0000469*Nj;
    double e = 0.01675;

    Kepler Equation (see details in Capderou 2012): \displaystyle u-e \sin(u) = M_t M_t anomalie moyenne, c’est M_t=L-\bar \omega
    u est l’anomalie excentrique
    Note that as we are in degree for u and M_t there is an extra factor \frac{180 }{\pi} : \displaystyle u-\frac{180 e}{\pi} \sin(u) = M_t Newton iteration to solve K(u)=0 with K(u)=u-e sin(u) -M_t and the derivative (note that there is no \frac{180 }{\pi} in it): \displaystyle K'(u)=\frac{dK}{du}= 1 - e \cos(u) Iteration, starting from u^0 = M_t, one or two is enough for the Sun as e is small: \displaystyle u^{n+1}=u^{n} - \frac{K(u^n)}{K'(u^n)}

        double Mt = fmod((L - omb),360);
    double u;
    u = Mt;
    u = u  - (u - e *180/pi*sindeg(u) - Mt)/(1 - e * cosdeg(u) );
    u = u  - (u - e *180/pi*sindeg(u) - Mt)/(1 - e * cosdeg(u) );

    Coordonnées écliptiques géocentriques du SOleil

    Cartesian position x and y of the Sun (Coordonnées écliptiques géocentriques: l,r).
    Relation entre u l’anomalie excentrique et v l’anomalie vraie et r :

    r= a(1-e \cos(u)) et x = a (\cos u -e) et y= a \sqrt{1-e^2}\sin(u)
    puis r=a (1-e^2)/(1+e \cos(v)) et \displaystyle \tan(\frac{v}{2})=\sqrt{\frac{1+e}{1-e}} \tan (\frac{u}{2})

        double x =  (cosdeg(u) - e);
    double y = sqrt(1 - e*e)* sindeg(u);
    double v = atan2(y,x)*180/pi;
    double r = 0.999721/(1 + e*cosdeg(v));
    double l = fmod(v + omb, 360);

    Coordonnées Astronomiques (coordonnées Equatoriales horaires)

    We now turn on the earth, wich axis of rotation is inclined by almost 23.437463405244976 ° (Meeus)
    the coordinates are “ascension droite” Asd and “déclinaison” \delta

        double atrop = 23.437463405244976;
    double delta = asin(sindeg(l)*sindeg(atrop))/pi*180;
    double Asd = fmod(24./360.*atan2(cosdeg(atrop)*sindeg(l),cosdeg(l))*180/pi, 24);
    double Asddeg = 360./24*Asd;

    temps Sidéral B p 84
    Local sideral time due to rotation of the Earth

    every 23h56min04.1s the earth is aligned with same stars 24 365.2425/(365.2425 + 1) = “23h56m4.09073s” indeed
    0.9856473415 1 + (23 + 56/60 + 4/3600)/24*360 \simeq 360

        double TSG360 = fmod(98.95958334 + 0.9856473415*(Nj) + heureTU/24*360, 360);
    double TSG24 = TSG360/360.*24 ;
    double TS360 = fmod(TSG360 - longit,360);
    double TS24 = TS360/360*24 ;

    Angle Horaire à 00:00 TU

        double AHv0 = fmod(TS360 - Asddeg, 360);

    Azimutal Coordinates of Sun

    Changement de coordonnées Equatoriales en Azimutales page 87 (et 91) Bouiges:
    H angle horaire TS-\alpha
    \delta déclinaison
    Az Azimut
    h hauteur
    \phi latitude du lieu d’observation \displaystyle \cos(\pi/2-h)=\sin(\phi)\sin(\delta) + \cos(\phi) \cos(\delta) \cos(H) \displaystyle \sin(Az)=(\cos(\delta)\sin(H))/\sin(\pi/2-h) \displaystyle \cos(Az)= ( -\cos(\phi)\sin(\delta) + \sin(\phi) \cos(\delta) \cos(H))/(\sin(\pi/2-h)) Calcul de la hauteur et Azimut (faire une procédure)

        double haut = asin(
                  sindeg(lat)*sindeg(delta) +
                  cosdeg(lat)*cosdeg(delta)*cosdeg(TS360 - Asddeg))*180/pi;
    double yy1 = (-cosdeg(delta)* sindeg(TS360 - Asddeg));
    double xx1 = (
           cosdeg(lat)*sindeg(delta) - sindeg(lat)*cosdeg(delta)*cosdeg(TS360 - Asddeg) );
    double Az = fmod(360+atan2(yy1,xx1)*180/pi, 360);

    hauteur = haut;
    azimut = Az;

    Check Sun

    control and comparisons to check

        if(check==1){
    fprintf(stdout, "#* * * * * * * * * * * *\n");
    fprintf(stdout, "#-----------------------\n");
    fprintf(stdout, "#The %2.f/%2.f/%4.f at UTC %s",J,M,A,HMS(heureTU,"h"));
    fprintf(stdout, " is Nj=%.2f Days since 00/01/1901 \n",Nj );
    fprintf(stdout, "#Temps Sidéral G = %s ",HMS(TSG360,"°"));
    fprintf(stdout, " Temps Sidéral Heures = %s",HMS(TSG24,"h"));
    fprintf(stdout, " Temps Sidéral local = %s\n",HMS(TS24,"h"));
    fprintf(stdout, "#-----------------------\n");
    fprintf(stdout, "# HP [EQ]  : r=%lf l=%lf H=%s",r,l,HMS(AHv0,"°"));
    fprintf(stdout, "  delta=%s \n",HMS(delta,"°"));
    fprintf(stdout, "# HP [E->A]: haut h=%s",HMS(haut,"°"));
    fprintf(stdout, " Azimut Z= %s\n",HMS(Az,"°"));
    fprintf(stdout, "#-----------------------\n");
    fprintf(stdout, "# Dec. val.: ");
    fprintf(stdout, "# Long=%.3f° Lat=0.000° haut=%.3f° Az=%.3f°  Asc drt=%.3fh  dec=%.3f° dist=%lf UA\n",
            l,haut,Az,Asd,delta,r);
    }

    Moon

    Moon is rising soon!
    Bouiges page 46
    Meeus page 111 …

    Many terms in the perturbation, others to be added soon!

    To determine moonLongitude, Bouiges uses 13 terms, Meeus 60

        double Lp= 33.231 + 13.17639653*Nj;
    double Op=239.882 - 0.052953922*Nj;
    double Mp=18.294  + 13.06499245*Nj;

    double moonLong = Lp + 6.28875*sindeg(Mp)
                         + 0.2136*sindeg(2*Mp)
                         + 0.6583*sindeg(2*(Lp-L))
                         - 0.1856*sindeg(2*Mt)
                         + 1.2740*sindeg(2*(Lp-L)-Mp)
                         - 0.1143*sindeg(2*(Lp-Op))
                         + 0.00001;

    double moonLat = 5.1280*sindeg(Lp-Op)
                   + 0.2806*sindeg(Mp+Lp-Op)
                   + 0.2777*sindeg(Mp-Lp+Op)
                   + 0.1732*sindeg( 2*(Lp-L)-(Lp-Op))
                   + 0.00001;

    Azimutal Coordinates of Moon

    Equatorial to Azimutal page 87 (and 91) Bouiges, or Meeus page 38 :
    H_{Moon} horar angle of Moon
    \delta_{Moon} Moon’s declinaison
    Az_{Moon} Azimuth of Moon
    h_{Moon} height of Moon
    \phi latitude \displaystyle \sin(h_{Moon})=\sin(\phi)\sin(\delta_{Moon}) + \cos(\phi) \cos(\delta_{Moon}) \cos(H_{Moon}) \displaystyle \sin(Az_{Moon})= (-\cos(\delta_{Moon})\sin(H_{Moon}))/\sin(h_{Moon}-\pi/2) \displaystyle \cos(Az_{Moon})= ( \cos(\phi)\sin(\delta_{Moon}) - \sin(\phi) \cos(\delta_{Moon}) \cos(H_{Moon}))/(\sin(h_{Moon}-\pi/2)) Compute Moon’s height and azimuth (should do a procedure)

        double moondelta=asin(sindeg(moonLat)*cosdeg(atrop) + cosdeg(moonLat)*sindeg(atrop)*sindeg(moonLong))/pi*180;
    double moonalpha = fmod(24./360.*atan2(cosdeg(atrop)*sindeg(moonLong)-tandeg(moonLat)*sindeg(atrop) ,cosdeg(moonLong))*180/pi, 24);
    double moonalphadeg=360./24*moonalpha;
    haut = asin(
                       sindeg(lat)*sindeg(moondelta) +
                       cosdeg(lat)*cosdeg(moondelta)*cosdeg(TS360 - moonalphadeg))*180/pi;
    yy1 = (-cosdeg(moondelta)* sindeg(TS360 - moonalphadeg));
    xx1 = (
                  cosdeg(lat)*sindeg(moondelta) - sindeg(lat)*cosdeg(moondelta)*cosdeg(TS360 - moonalphadeg) );
    Az = fmod(360+atan2(yy1,xx1)*180/pi, 360);

    Check Moon

    control and comparisons to check
         if(check==1){
         moonLong=fmod(moonLong,360);
         fprintf(stdout, "# Moon: Long=%.3f° lat=%.3f° --- alpha=%.3fh delta=%.3f° --- Z_moon=%.3f° h_moon =%.3f°  \n",
                 moonLong,moonLat,fmod(24+moonalpha,24),moondelta,Az,haut);

     }
    return;
}

    Main

    int main() {

    check the values (comparison with Ephémérides etc) in file log

        check=1;
    fprintf(stdout, " # check 26/04/2020 at UTC 16:00\n");
    calc(26,04,2020,16,48+48./60+45./3600,-(2+20./60+33./3600));
    fprintf(stdout, "\n\n # check 10/05/2020 at UTC 13:45\n");
    calc(10,05,2020,13.75,48+48./60+45./3600,-(2+20./60+33./3600));
    //calc(12,04,2011,0,0,0);
    //calc(10,05,1989,0,0,0);
    //  exit(0);
    check=0;

    to be done: compute at present time

        time_t timestamp = time(NULL);
    struct tm * now = localtime( & timestamp );
    int AAAA,MM,JJ,HH,mim;
    AAAA=1900+now->tm_year;
    MM=now->tm_mon+1;
    JJ=now->tm_mday;
    HH=now->tm_hour-2.; //summertime
    mim=now->tm_min;
    fprintf(stdout, "#-----------------------\n");
    fprintf(stdout, "# today is %2d/%2d/%4d at UTC=%2d:%2d\n",JJ,MM,AAAA,HH,mim);
    calc(JJ,MM,AAAA,HH+mim/60.,48+48./60+45./3600,-(2+20./60+33./3600));
   // fprintf(stdout, "# hauteur=%s ", HMS(hauteur,"°"));
   // fprintf(stdout, ", azimut=%s \n\n",HMS(azimut,"°"));
    fprintf(stdout, "# hauteur= %lf azimut=%lf\n", hauteur,azimut);

    position of the shadow every month in 2020, rotation of the plate 43° (axis of Cité Verte), if the plate is vertical, other rotations are required. Mind the minus sign (clockwise rotation!)

        double rot=43;
    for(double m=1;m<=12;m++)
    {
    for(double h=8;h<=16;h+=.25)
    {
     calc(21,m,2020,h,48+48./60+45./3600,-(2+20./60+33./3600));
     fprintf(stdout, " %lf, %lf %lf\n",fabs(1/tandeg(hauteur))*cosdeg(-azimut  + rot),
                   fabs(1/tandeg(hauteur))*sindeg(-azimut  + rot),m);
    }
         fprintf(stdout, "\n");
    }

    save hours for 3 representative months

        FILE * fp = fopen ("hours.txt", "w");
    for(double h=8;h<=16;h+=1)
    {
        calc(21,12,2020,h,48+48./60+45./3600,-(2+20./60+33./3600));
        fprintf(fp, " %lf, %lf %2.2f \n",fabs(1/tandeg(hauteur))*cosdeg(-azimut  + rot),
                fabs(1/tandeg(hauteur))*sindeg(-azimut  + rot),h);
        calc(21,6,2020,h,48+48./60+45./3600,-(2+20./60+33./3600));
        fprintf(fp, " %lf, %lf %2.2f \n",fabs(1/tandeg(hauteur))*cosdeg(-azimut  + rot),
                fabs(1/tandeg(hauteur))*sindeg(-azimut  + rot),h);
        calc(20,3,2020,h,48+48./60+45./3600,-(2+20./60+33./3600));
        fprintf(fp, " %lf, %lf %2.2f \n",fabs(1/tandeg(hauteur))*cosdeg(-azimut  + rot),
                fabs(1/tandeg(hauteur))*sindeg(-azimut  + rot),h);
    }
    fclose (fp);
    fp = fopen ("hoursTD.txt", "w");
    for(double h=8;h<=16;h+=.5)
    {
        calc(JJ,MM,AAAA,h,48+48./60+45./3600,-(2+20./60+33./3600));
        fprintf(fp, " %lf, %lf %2.2f \n",fabs(1/tandeg(hauteur))*cosdeg(-azimut  + rot),
                fabs(1/tandeg(hauteur))*sindeg(-azimut  + rot),h);
    }
    fclose (fp);

    The position of the shadow at UTC 12:00 draws the analemma

        for(double m=0;m<=12;m+=.25){
        calc(1,m,2020,12,48+48./60+45./3600,-(2+20./60+33./3600));
        fprintf(stdout, " %lf, %lf \n",fabs(1/tandeg(hauteur))*cosdeg(-azimut  + rot),
                fabs(1/tandeg(hauteur))*sindeg(-azimut  + rot));
    }

    The equation of time at Greewich: one Newton step to find the time T for which azimut is South: Z=180), difference (T-12) is the “equation of time”.

        fp = fopen ("edt.txt", "w");
    for(double j=0;j<=365;j++){
        calc(j,1,2020,12,48+48./60+45./3600,0);
        double azimut12=azimut;
        calc(j,1,2020,12.1,48+48./60+45./3600,0);
        double dadt=(azimut-azimut12)/.1;
        double heure180 = 12 - (azimut12-180)/dadt;
        calc(j,1,2020,heure180,48+48./60+45./3600,0);
        heure180 = heure180 - (azimut-180)/dadt;
        fprintf(fp, " %lf, %lf \n",j,heure180);
    }
    fclose (fp);
    fprintf(stderr," no error, just to compute today the %2d/%2d/%4d at UTC=%2d:%2d\n",JJ,MM,AAAA,HH,mim);
    //exit (1); // always fails (forces rerun)
}

    Results

    Exemple of Values for a given position and date

    Exemple of computation from Meeus 1986 implementation http://xjubier.free.fr/site_pages/astronomy/ephemerides.html
    26 April 2020 16:00 UTC, position 48°48’45’‘N, 2°20’33’‘E, so negative: -(2+20./60+33./3600) at the “Cité Verte” (close to Parisian meridian 2°20’14’)

     #* * * * * * * * * * * *
 #-----------------------
 #The 26/ 4/2020 at UTC 16h 0mn0.0s is Nj=43581.67 Days since 00/01/1901
 #Temps Sidéral G = 95° 6mn48.5s  Temps Sidéral Heures = 6h20mn27.2s Temps Sidéral local = 6h29mn49.4s
 #-----------------------
 # HP [EQ]  : r=1.006472 l=36.886502 H=62°54mn25.7s  delta=13°48mn44.1s
 # HP [E->A]: haut h=28° 5mn35.9s Azimut Z= 258°31mn3.4s
 #-----------------------
 # Dec. val.: # Long=36.886502 Lat=0.00 haut=28.093306 Az=258.517622  Asc drt=2.303256  dec=13.812241 dist=1.006472
    from Meeus implementation —-> this program Error
    Long 36°52’27,03" = 36.8742 —-> l = 36.886502 0.01°
    Lat 00°00’00,00“ —-> 0° 0°
    hauteur 28°04m48.s = 28,08° —-> haut = 28°05mn35.9s =28.093306° 0.01° (1111m)
    Azimut 258°31m12.s = 258,52° —-> Azimut Z= 258°31mn3.4s = 258.517622° 0.002°
    Asc Drt 2h18m08,89s 2.303256 —-> Asc drt=2.303256° 0.00°
    déclinaison 13° 48’ 27,65" —-> delta=13°48mn44.1s 017’’
    dist 1,0064877 U —-> r=1.006472 0.000157

    Example of anual sundial plot

    Plot of path of Sun, the 21 of each month 1,2,3…12 with the UTC hours the 21/12, left bottom, 20/03 and 21/06 right top (2 and 10, 1 and 11, 3 and 9 (march and september), 4 and 8, 5 and 7 are almost superposed), with an analemma at noon.

    The motto “transibunt et augebitur Scientia” is on the sundial of Cuvier’s house, Jardin des Plantes (see Camus Gotteland 1993, http://michel.lalos.free.fr/cadrans_solaires/autres_depts/paris/cs_paris_05.html)

     reset
 set size square
 set title "transibunt et augebitur Scientia "
 set label 1 at 0,0 "  Gnomon"
 set label 12 at -2.25,-4.75 "December"
 set label 6 at 1.25,-1.35 "June"
 set label 3 at 1.25,-3 "March"
 set object circle at first 0,0 radius char 0.5 \
 fillstyle empty border lc rgb '#aa1100' lw 2
 p[-5:2][-5:2]'out' u 1:2 w l not,\
 'hours.txt' lc rgb '#aa1100' pt 7  ps 1  not,\
 '' with labels center offset 3.4 not,\
 'hoursTD.txt' w lp lc 3 t'today from 08:00 every 30min"
 unset label 12
 unset label 1
 unset label 3
 unset label 6
    (script)

    (script)

    Example of sundial for one day plot

    The sundial at the day of the computation, for Cité Verte orientation.
     reset
 set size square
 set title "transibunt et augebitur Scientia "
 set label 1 at 0.15,0.25 "Gnomon length,\nand gnomon position"
 set arrow 1  nohead from 0,0 to 0,1
 set arrow 2  nohead from -.5,0 to 0.5,0
 set object circle at 0,0 radius  .05
 p[:1.5][:1.5]'hoursTD.txt' using 1:2:($3-int($3)<0.5? sprintf("%d:00", $3): " ") with labels point  pt 7  offset 2.5,0 notitle,'' w l linec -1 not
 unset arrow 1
 unset arrow 2
 unset label 1
    (script)

    (script)

    Equation of time.

    This corresponds to the Analemma: azimut is not exactly 180° at UTC=12:00, there is a variation in time called “equation of time” visible in practice through the plot of Analemma. This is the difference in time between “true” an “apparent” sun. Here is the procedure we use to compute equation of time in Greewich: find the hour at which Z=180 substract 12h and put in minutes. It depens on the obliquity of earth axis \varepsilon and on the excentricty e of the path of the earth. The Meeus 1988,2014 formula is presented as a good approximation \displaystyle \Delta=\frac{5}{4} e^2 \sin \left(\frac{\pi M}{90}\right)-4 e y_o \cos \left(\frac{\pi L}{90}\right) \sin \left(\frac{\pi M}{180}\right)+2 e \sin \left(\frac{\pi M}{180}\right)+\frac{1}{2} y_o^2 \sin \left(\frac{\pi L}{45}\right)-y_o \sin \left(\frac{\pi L}{90}\right)\text{ with } y_o= \tan ^2\left(\frac{\pi \varepsilon}{360}\right) where \displaystyle L = 280.46646 + 36000.76983 T + 0.0003032 T^2 \displaystyle M=357.52911 + 35999.05029 T - 0.0001537 T^2, \displaystyle \varepsilon = 23 + (26*60 + (21.448 - T (46.815 + T (0.00059 - T 0.001813))))/60/60, \displaystyle e =(0.016708634 - 0.000042037 T + 0.0000001267 T^2); where T the number of centuries since 01/01/2000, so number of days divided bay 36525. It is not plotted here, but it has been checked that the difference between Meeus formula and this programm is 15 seconds (of hour) at most.

    Meeus formula is simplified in a simple approximation tacking into account obliquity and excentricty as a function of j the day of the year, the first of january j=1, and j=81 at spring equinox. the approximate “equation of time” (https://fr.wikipedia.org/wiki/Équation_du_temps) is just: \displaystyle \Delta=7.678 \sin(B(j) + 1.374) - 9.87 \sin( 2 B(j)) \text { with } B(j)=2 \pi (j - 81)/365 It represents well the actual result:
     set title " equation of time (french sign)"
 set xlabel "day in year"
 set ylabel "difference in min"
 B(x)=2*pi*(x - 81)/365.
 edt(x)=7.678*sin(B(x) + 1.374) - 9.87*sin( 2*B(x))
 p[0:365] edt(x) t'simple approximation','edt.txt'u 1:(($2-12)*60) t'computed'
    (script)

    (script)

    Conclusion

    Position of sun and moon (not fully finshed yet) usefull for tides (see maree_bretagne.c), navigation.

    Position of sun : Bagnold sun compass, invented by Bagnold.

    Biblio



    conf Avril 2020
